Product Name: AVR MX321
Model Number: MX321
Certificate: CE,RoHS,ISO9001
Function: Automatic Voltage Regulator AVR
Quality Class: A grade high quality
Warranty: 1 Year
Selling Units: Single item
Single gross weight:0.80 kg
Supply Ability: 5000 Piece/Pieces per Month
Function: Stabilize and regulate voltage, Replaced for generator avr
Packaging Details: Each one into small inner box then into Strong Export Standard Carton

Email us

Generator AVR MX321 Circuit Diagram Automatic Voltage Regulator AVR

Generator AVR MX321 Circuit Diagram Specifications:

Generator Spare Part Automatic Voltage Regulator AVR Red Capacitors MX321

Generator Spare Part Automatic Voltage Regulator AVR Red Capacitors MX321 is a half-wave phase controlled thyristor type Automatic Voltage Regulator and forms part of the excitation system for a brushless generator. In addition to regulating the generator voltage, the AVR circuitry includes under speed and sensing loss protection to ensure safe, reliable control of the generator.

Positive voltage build up from residual levels is ensured by the use of proficient semiconductors in the power circuitry of the AVR. Which is linked with the main stator windings and the exciter field windings to offer closed loop control of the output voltage with load regulations of +/- 1.5%

Technical sepcification
Sensing/Power input	Voltage	Jumper selectable 190-240V ac
	Frequency	50-60 Hz nominal
	Phase	1
	Voltage	Max 95V ac at 240V ac input
Magnetic Field Output	Current	Continuous 20A
Magnetic Field Output	Resistance	15 ohms minimun
Pressure Regulating Accuracy		<±1% RMS with 4% engine govern

Generator AVR MX321 Circuit Diagram Fetures:

MX321 is a half-wave phase controlled thyristor type Automatic Voltage Regulator and forms part of the excitation system for a 1000KW below brushless generator.

1. Fireproof and heat-insulating soft rubber compared to ordinary soft rubber, we reach the military level.
2.High temperature resistant shell, no deformation in high temperature environment, no cracking.
3.EPCOS capacitor has good temperature stability and high precision

4.High quality capacitance, good parameter consistency and high reliability.

How to choose Stanford Generator AVR
Generator/AVR	SA465	SA465	SX460	SX440	SX421	MS341	MX321
BC16			STD
BC182			STD
BC184	AUX WDG	OPT	STD		LOOSE
UC224			STD	OPT	OPT	OPT(PMG)	OPT(PMG)
UC274			STD	OPT	OPT	OPT(PMG)	OPT(PMG)
HC4				STD	OPT	OPT(PMG)	OPT(PMG)
HC5				STD	OPT	OPT(PMG)	OPT(PMG)
HC6							STD
HC/MV7							STD
